Thermal Hi-limit Snap Switches

AMP: 15 at 110V,
AMP: 10 at 220V
1/4" Male Spade Lug Terminals
Normally Closed
UL / CSA Rated, Bimetal Switch Componenets
Heavy-Duty Brass Housing - 7000 PSI Collapse Rating
Normally used with other adjustable or fixed range thermostat which regulates water temperature
Does not turn back on until water has cooled 50° - 70°F
Operates as a safety device to shut off burner to prevent machine (water) overheating flashing to steam

Probe MPT: 3/8" x /1/2"
Temp: 120°F
  • Part No: 8.712-301.0
  • PSI: 4000
  • Temperature: 120°F
  • AMP: 10/15
  • Voltage: 110/220

* Please note part number for reference when contacting your local dealer.
